Pleated Hydrophilic PTFE Membrane and Polypropylene Supported Cartridges for Microelectronic Liquid



The Proflow?-HE cartridge is designed for filtration of microelectronic (MiE) fluids. High-purity polypropylene and hydrophilic PTFE provide an economical alternative for the filtration of various MiE chemicals. The hydrophilic nature of the PTFE membrane does not require pre-wetting for aqueous based liquids typically necessitated with standard PTFE membranes. This can reduce total operating cost and improve process up-times.

Proflow?-HE is available in both Standard and SELECT pleated versions. SELECT pleating allows for additional membrane surface areas for exceptional flow rates and on-stream life.

Proflow?-HE cartridges are manufactured in an ISO 9008 certified Class 10,000 cleanroom and flushed with ultra-high-purity deionized water and 100% integrity tested as well as serialized to provide complete product purity, reliability and traceability.

Parker Proflow?-HE Cartridge Applications:

• Recommended applications include, but are not limited to:
• Acids & Bases
• Extraction/crystallization solvents
• Hot ultra-high-purity deionized water
• Solvent filtration

Parker Proflow?-HE Cartridge Benefits:

• Hydrophilic membrane (pre-wetting not required)
• Broad chemical compatibility
• Long service life minimizes changeout frequency
• Low differential pressure reduces energy costs
• Top-performing retention efficiency
• Very low metals and organic extractables
• Quick rinse up-time
• Integrity-tested for quality assurance

Parker Proflow?-HE Cartridge Markets:

Proflow?-HE is well-suited for the manufacturing of:

• LCD Displays
• Solar Panels
• Bulk Chemicals
• Fine Chemical Filtration

Parker Proflow?-HE Cartridge Specifications:




Materials of Construction
Membrane:     Hydrophilic PTFE
Support layers:     Polypropylene
Structure:     Polypropylene

Materials are thermally bonded, for maximum assurance of filter integrity and elimination of bonding or sealing compounds. Modules and final filter assemblies are flushed with 18-meg-ohm-cm high purity water, to provide extremely low extractables levels.

Effective Filtration Area
Standard Pleating: 7.2 ft2*
SELECT Pleating: 11.4 ft2*
* Per 10-inch (250mm) cartridges

Maximum Differential Pressure
Forward:
70 psid (4.8 bar) @ 75°F (24°C)
40 psid (2.8 bar) @ 180°F (82°C)
Reverse:
40 psid (2.8 bar) @ 75°F (24°C)

Cleanliness (Particle Shedding)
20 gal rinse-up at 1gpm achieves <1 particle/ml @ 0.2 m

Chemical Compatibility
Compatible with many water based acids, basis & solvent solutions.
Contact dhP-N.A. Technical Services for details.


Download Parker Proflow HE Cartridge Datasheet

Talk to one of our filtration experts today at (855) 737-4717 or fill out our online form to learn more.
