Absolute-Rated Polypropylene Depth Cartridges for Electronics Applications
Polyflow cartridges are optimized for use in electronics applications. They feature a random-fiber polypropylene depth matrix that provides excellent retention efficiencies and onstream life. The unique calendering process produces depth media with an absolute rating and superior dirt-holding capacity.
These cartridges are thermally bonded from 100% virgin polypropylene to ensure a high level of cleanliness and chemical compatibility.
Parker Polyflow? Cartridge Benefits:
- High-retention depth matrix
- High flow rate
- Wide variety of configurations and ratings
- Economical prefiltration
Parker Polyflow? Cartridge Applications:
- Solder plating
- Prefiltration of electronics-grade chemicals
- DI water
Parker Polyflow? Cartridge Specifications:
Materials of Construction
Depth media: Polypropylene
Support layers: Polypropylene
Structure: Polypropylene
All components are thermally bonded to ensure integrity and minimize extractables.
Effective Filtration Area
2.4ft2 (0.22 m2) 5 (130mm) cartridges
4.9ft2 (0.46 m2) 10 (250mm) cartridges
Filtration Efficiency
The 0.6m offers typical retention up to 99% efficient. 1.2m, 2.5m, 5m, 10m, 20m, and 40m are up to 99.9% efficient at specified pore size.
Cartridge Extractables
NVR < 35mg per 10 (250mm) cartridges
Maximum Differential
Pressure/Temperature
Forward:
80psid (5.5bar) @ 75°F (24°C)
Reverse:
40psid (2.8bar) @ 75°F (24°C)
15psid (1.0bar) @ 140°F (60°C)
Maximum Operating Temperature
160°F (71°C)
Download Parker Polyflow Cartridge Datasheet
Talk to one of our filtration experts today at (855) 737-4717, or fill out our online form to learn more.
