High Performance All-Fluoropolymer Cartridge for Aggressive Applications
The Fluoroflow?-SELECT filter cartridge provides exceptional flow rates and on-stream life. It utilizes our unique SELECT pleating technology that increases filtration area and flow rate by over 70% versus our standard Fluoroflow?. This results in increased bath turnover and longer filter lifetime demanded by todays fabs. The all-fluoropolymer construction provides excellent chemical resistance for the most aggressive applications up to 180C. Available wet-packed for quick installation or Ultraclean wet-packed which offers the lowest metals extractables in the industry.
Parker Fluoroflow?-Select Cartridge Benefits:
- Large fltration area for longer life
- High fow rates for increased bath turn over
- Wet-pack option for quick installation
- Ultraclean wet-pack option for absolute cleanliness
- All-fuoropolymer for maximum chemical resistance
- 100% integrity tested for consistent quality
Parker Fluoroflow?-Select Cartridge Applications:
- Wet etch and clean
- Phosphoric acid
- Sulfuric acid
- Hydrof uoric acid
- Nitric acid
- Piranha SC1,SC2
- NMP-based solvents
- Other high temperature or ozonated processes
Parker Fluoroflow?-Select Cartridge Specifications:
Materials of Construction
100% Fluoropolymer construction
All components are thermally bonded to ensure integrity and reduce extractables.
Effective Filtration Area
6.0ft2 (0.56 m2) 4" (100mm) cartridge
12.2ft2 (1.1 m2) 10" (250mm) cartridge
Metals Extractables*
Standard: <20ppb (total)
Ultraclean: <5ppb (total)
*In a 10% HNO3 extraction
Maximum Differential
Pressure/Temperature
Forward:
80psid (5.5bar) @ 75°F (24°C)
55psid (3.8bar) @ 167°F (75°C)
30psid (2.0bar) @ 257°F (125°C)
15psid (1.0bar) @ 300°F (150°C)
Forward HT option:
100psid (6.8bar) @ 75°F (24°C)
75psid (5.1bar) @ 167°F (75°C)
50psid (3.4bar) @ 257°F (125°C)
15psid (1.0bar) @ 356°F (180°C)
Reverse:
50psid (3.4bar) @ 75°F (24°C)
15psid (1.0bar) @ 250°F (121°C)
Cleanliness (particle shedding)
Wet-packed: <2 particles/ml >0.2m after 7gal @ 1gal/min
Dry-packed: <2 particles/ml >0.2m after 12gal @ 1gal/min
TOC/Resistivity Rinse-up (wet-packed)
TOC recovery within 3-5ppb of feed without additional rinse-up.
Resistivity recovery within 0.4megohm-cm of feed after 22gal @ 1gpm.
